Basic Package
Components included:
- RX-Basic: Value Plan - Support up to 10 measurement with 1 hour logging
- EU Compatible AC Power Adapter
- HOBOnet Leaf Wetness Sensor - 921 MHz Taiwan
- HOBOnet Solar Radiation (Silicon Pyranometer) Sensor -
- HOBOnet Rainfall (inches) Sensor - 921 MHz Taiwan
- RX Runtime Smart Sensor
- HOBOnet Soil Moisture EC-5 Sensor - 921 MHz Taiwan
- HOBOnet Multi-Depth Soil Moisture Sensor - 3 Segment Probe
- HOBOnet Wireless Temperature Sensor - 1 Foot Cable
- Water Level Sensor - 4m (13’) Stainless Steel
- RX3000 Relay Module
Intermediate Package
Components included:
- RX-StandardAdvanced Monitoring with Standard Sensor Support | Up to 25 measurements with 5 minute logging
- Solar panel: 5 Watt Solar Panel
- HOBOnet Leaf Wetness Sensor
- HOBOnet Solar Radiation (Silicon Pyranometer) Sensor
- HOBOnet Rainfall (metric) Sensor
- HOBOnet Wireless Temp/RH Sensor
- RX Runtime Smart Sensor
- HOBOnet Soil Moisture 10HS Sensor
- HOBOnet Multi-Depth Soil Moisture Sensor - 4 Segment Probe
- HOBOnet Wireless Temperature Sensor - 6 Foot Cable
- Water Level Sensor - 76m (250’) Stainless Steel
- RX3000 Relay Module
Advanced Package
Components included:
- RX-PremiumAdvanced Monitoring with Best Sensor Support | Supports Devices Max Sensors and Logging Rate
- Solar panel: 15 Watt Solar Panel
- HOBOnet Leaf Wetness Sensor
- HOBOnet Solar Radiation (Silicon Pyranometer) Sensor
- HOBOnet Rainfall (metric) Sensor
- HOBOnet Wireless Temp/RH Sensor
- RX Runtime Smart Sensor
- HOBOnet T11 Soil Moisture/Temp Sensor
- HOBOnet Multi-Depth Soil Moisture Sensor - 6 Segment Probe
- HOBOnet Wireless Temperature Sensor
- Water Level Sensor - 76m (250’) Stainless Steel
- HOBOnet Ultrasonic Wind Speed & Direction Sensor
- RX3000 Relay Module
Specifications :
Soil Measurement:
- Soil Moisture Range: 0–100% volumetric water content (VWC)
- Soil Temperature Range: -40°C to 75°C (-40°F to 167°F)
- Accuracy: ±2% VWC, ±0.2°C temperature
Data Logging & Channels:
- Channels: Up to 12 wired or wireless soil sensors
- Logging rate: 1 second to 18 hours
- Memory: 1,000,000 measurements
Power & Solar:
- Voltage rating: 12–15 V DC
- Solar panel supported: 5–10 W with battery backup
Connectivity & Remote Access:
- Options: Ethernet, WiFi, cellular, or satellite modem
- Web-based dashboard for remote monitoring and data download
- Configurable alarms for threshold exceedances
Operating Range:
- Temperature: -40° to 75°C (-40° to 167°F)
- Weatherproof housing for outdoor deployment
HOBOnet Leaf Wetness Sensor
-
Measures leaf surface wetness for plant and irrigation monitoring.
-
Accuracy: Detects presence/absence of water droplets; provides resistance-based signal.
-
Operating range: 0° to 50°C (32° to 122°F); outdoor compatible.
HOBOnet Soil Moisture 10HS Sensor
-
Measures volumetric water content (VWC) in soil.
-
Range: 0–100% VWC; Accuracy: ±2% VWC.
-
Operating temperature: -40° to 50°C (-40° to 122°F).
HOBOnet Multi-Depth Soil Moisture Sensor
-
Monitors soil moisture at multiple depths with one sensor unit.
-
Compatible with 12–24 V logger input or wireless interface.
-
Accuracy: ±2% VWC; Depths configurable per installation.
HOBOnet Wireless Temperature Sensor
-
Measures air or soil temperature.
-
Range: -40°C to 75°C (-40°F to 167°F).
-
Wireless range: ~100 ft (30 m) line-of-sight to receiver.
Water Level Sensor
-
Measures water level and depth for rivers, tanks, or ponds.
-
Range: Typically 0–10.3 m (0–34 ft); Accuracy ±0.05% of full scale.
-
Output: Compatible with RX3000 logger or wireless interface.
HOBOnet Rainfall (Metric) Sensor
-
Measures precipitation in metric units (mm/hour).
-
Range: 0–10.2 cm/hr (0–4 in/hr).
-
Operating temperature: 0° to 50°C (32° to 122°F).
HOBOnet Wireless Temp/RH Sensor
-
Measures air temperature (-40° to 75°C) and relative humidity (0–100% RH).
-
Accuracy: ±0.2°C for temperature, ±2% RH.
-
Wireless transmission: 921 MHz; line-of-sight up to ~100 m.
